| Camera |
| Image Sensor |
1/3 inch Progressive Scan CMOS |
| Max. Resolution |
2560 × 1440 |
| Min. Illumination |
Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0.005Lux @(F2.0, AGC ON), 0 Lux with IR |
| Lens |
| Focal Length |
2.8 mm; 4 mm |
| FOV |
4mm: Horizontal field of view: 69.9°, vertical field of view: 34.9°, diagonal field of view: 84.9°
2.8mm: Horizontal field of view: 91.1°, vertical field of view: 47.9°, diagonal field of view: 110.8° |
| Aperture |
4mm: F1.6
2.8mm: F2.0 |
| Illuminator |
| Supplement Light Type |
IR,White Light |
| Supplement Light Range |
IR distance: up to 20 m,White light distance: up to 15 m |
| IR Wavelength |
850 nm |
| PTZ |
| Movement Range (Pan) |
0° to 350° |
| Movement Range (Tilt) |
0° to 75° |
| Pan Speed |
Up to 20°/s |
| Tilt Speed |
Up to 10°/s |
| Video |
| Main Stream |
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 20 fps (2560 × 1440), 24 fps (1920 × 1080, 1280 × 720) |
| Sub-Stream |
50 Hz: 25 fps (768 × 432)
60 Hz: 30 fps (768 × 432) |
| Video Compression |
H.265, H.264, MJPEG |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.265 Type |
Main Profile |
| Audio |
| Audio Compression |
G.711ulaw/AAC-LC |
| Audio Bit Rate |
AAC-LC: 16 Kbps, 32 Kbps, 64 Kbps; G.711ulaw: 64 Kbps |
| Audio Sampling Rate |
8 kHz/16 kHz |
| Environment Noise Filtering |
Yes |
| Network |
| Protocols |
IPv4/IPv6, HTTP, QoS, SMTP, NTP, RTSP, RTP, RTCP, TCP/IP, UDP, DHCP, Bonjour |
| API |
Open Network Video Interface (Version 18.12, Profile S, Profile G, Profile T), ISAPI, SDK, Hik-Connect |
| User/Host |
Up to 32 users. 3 levels: Administrator, Operator and User |
| Security |
Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address) |
| Client |
Wired network: Hik-Connect, iVMS-4200
Wi-Fi: iVMS-4200
*Wi-Fi connection with Hik-Connect directly is not possible |
| Wireless (Wi-Fi) |
| Wi-Fi Protocols |
IEEE802.11b,IEEE802.11g,IEEE802.11n |
| Frequency Range |
2.4 GHz to 2.4835 GHz |
| Channel Bandwidth |
20/40 MHz |
| Modulation |
802.11n: QPSK, BPSK, 16QAM, 64QAM,
802.11b: CCK, QPSK, BPSK,
802.11g: QPSK, BPSK, 16QAM, 64QAM |
| Transfer Rate |
11n: up to 300 Mbps |
| Image |
| Image Settings |
Saturation, brightness, contrast, and sharpness adjustable by client software or web browser |
| Wide Dynamic Range (WDR) |
Digital WDR |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Privacy Mask |
4 programmable rectangle privacy masks |
| Interface |
| Ethernet Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| Built-in Microphone |
1 built-in microphone |
| On-board Storage |
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
| Built-in Speaker |
1 built-in speaker |
| Event |
| Basic Event |
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception |
| Linkage |
notify surveillance center, send email, trigger recording, trigger capture, audible warning |
| General |
| Power |
12 VDC ± 25%, reverse polarity protection, 0.75 A, max. 9 W, Ø 5.5 mm coaxial power plug |
| Dimension |
Ø 124 mm × 119 mm |
| Weight |
Weight:Approx. 290 g (0.6 lb.)
With Package Weight:Approx. 390 g (0.8 lb.) |
| Material |
Plastic |
| Operating Condition |
-10 °C to 40 °C (-14 °F to 104 °F). Humidity 90% or less (non-condensing) |
| General Function |
Heartbeat,anti-banding,mirror,password protection,password reset via email |
| Approval |
| Protection |
IP54 |
| General |
| Language |
English, Ukrainian |
